CNC Wood/Stone Router
Salient Features
- Cast Iron/Steel Fabricated Bed Structure, Robust and without distortion.
- Y axis Double Motor Driving System ensures Stable & Smooth Movement.
- High Precision Rack Gear Transmission ensures fast speed & High Accuracy.
- T-slot Aluminum Table with Dust Collector
- Lead shine Stepper Motors & Drives.
- Automatic Lubrication System.
- High Precision Taiwan ball screw & L M Guide
- Easy to maintain, cutting surface is smooth, saving time and labor.
Application Accessories
- Dust Collector
- Auto Tool Changer
- Water Chiller
- Servo Stabilizer
- Servo Motor and Drives
- SPM
Job Sample
Standard Accessories
- Leveling Pads
- Tool Kit
Technical specifications
| Technical Specification | Unit | JK-1325WR | JK-1530-5A |
|---|---|---|---|
| Travel of working table (X Axis) | mm | 1300 | 1500 |
| Travel of working table (Y Axis) | mm | 2500 | 3000 |
| Travel of working (Z Axis) | mm | 200 | 600 |
| Spindle | Kw | 3Kw Water Cooling | 9Kw (HSD) |
| Spindle Rotating Speed | rpm | 3000 ~ 24000 | |
| X, Y Position Accuracy | mm/min | ± 0.05 | |
| Max. Cutting Speed | mm/min | 20000 | |
| Max. Rapid Travel | mm/min | 30000 | |
| Graphic Format | - | G-code / u00 / MMG / PLT | |
| Compatible Software | - | Corel Draw / Auto Cad / Photoshop | |
| Control System | - | DSP / NC Studio | |
| Working Voltage | V | AC230V SINGLE PHASE / AC415V/50Hz 3 PHASE | |
| Connected Load | Kw | 3 | 15 |
| Drive & Motor | - | Stepper/Servo Motor & Drive | |
| Machine Weight | Kg | 1800 | 3000 |
